Disaster Black Box System Technical Specifications
Technical Specifications
| Item | Detail |
|---|---|
| Body | Carbon Fibre PLA Reinforced with Special Printing Technique. |
| Main Board | ESP32 S3 Main Board |
| Screen | 4.7 inch 960*540 Resolution E-Paper Grayscale Touch Screen |
| Network Connectivity | Wi-Fi Bluetooth V5.0 |
| Power Supply | 5V USB Type-C |
| Battery | 3 x 3.7V Panasonic MH12210 Lithium Ion Battery |
| Warning Component | 3V Buzzer |
| Motion Sensor | RCWL-0516 Microwave Radar Module |
| Sound Detector | MAX4466 OPAMP Volume Adjustable Detection Module |
| Accelerometer | MPU6500 3 Axis Accelerometer |
| Gyroscope | MPU6500 3 Axis Gyroscope |
| Carbon Dioxide Sensor | SCD30 Carbon Dioxide Sensor with 10.000/1 ppm Sensitivity |
| Temperature Sensor | SCD30 Temperature Sensor |
| Humidity Sensor | SCD30 Humidity Sensor |
| Vibration Motor | 13100 1.5-9V Vibration Motor |
| Dimensions | 16cm X 9cm X 5cm |
| Weight | ≈ 500 gr |
| Resilience | >= 4.1 kJ/m² (Increased by Printing Technique) |
| Energy Consumption | 0.4W/hour in Full Operation Mode - 0.23W/hour in Demolition Mode |
| Battery Operation Time | 60 Hours |
| Operation Time in Demolition Mode | 72-96 Hours |
| Software Language | C++ |
| Server API Connection | Once per hour in Normal Mode. Instantaneous in Risk Situation. Every 10 minutes in Disaster. |
